Auto hydraulic lift Palfinger P 640

The PALFINGER P 640 is an aerial work platform with impressive working height, outreach, and load capacity boosted by Powerlift. Mountable on a 32 t chassis, it features a 240° X-Jib and 2×200° basket rotation for precise and flexible maneuverability even in demanding environments. Built with special profile structures and lightweight materials to minimize dead weight, allowing the vehicle to carry more tools, accessories, and materials. The 540° turntable slewing angle enables work above and behind buildings. The telescopic upper boom combined with the X-Jib extends maximum reach up to 19 m. An automatic telescope lubrication system reduces downtime and extends component life. Working height: 64 m, side reach: 40.5 m, basket load: 600 kg, turntable rotation: 540°, overall weight: 29,000 kg.

Leveling Made Simple

Automatic leveling saves time and ensures peak performance on work platforms

Convenient Stabilizer System

Achieve stability fast with just the touch of a button thanks to PALFINGER’s automatic support leveling feature

Perfect Protection

The KTL coating provides optimal, long-lasting surface protection with excellent corrosion resistance for the whole life of a platform, maintaining performance and helping to retain value

One Button Folding
